THE TOMAHAWK
KEY FEATURES
– Unparalleled LF performance
– Useable Output to 25hz
– Extreme Powerhandling
– Truck-pack Friendly dimensions
APPLICATIONS
Suitable for any application where
extreme low frequency extension
and output is required.
The Tomahawk is a truck-pack friendly version of the BattleAxe, featuring integrated handles, and is a high intensity Front Loaded Horn designed for very deep extension, with an intended passband 28hz-100hz, employing a 24db/octave 25hz buttersworth hipass.
This enclosure is optimized for clusters of 4 or more, with optimum sensitivity being achieved from a block of 8. However, the output from a single BattleAxe is nothing short of stunning. This enclosure is available in 4ohm or 8ohm specifications.
System Alignment: 21 Inch loaded Front Loaded Horn
System Response (-10db): 22hz
Frequency Response (-3db): 28hz-150hz
Power Rating (Continuous Program Peak): 1700w/3400w/7000w
Sensitivity (Iw/I meter): 107db
Nominal Impedance: 4 ohm or 8 ohm available
Reccomended Processing: 4 ohm 25hz, 24 db/octave Buttersworth Hi-pass, 60-100hz Low-pass
Enclosure Construction: Precision CNC construction, 18mm Baltic birch 30mm baffle
Exterior Coatings: Polane (Custom Colors Available)
Grille Specifications: Optional 16 Gauge Black Powder-coated steel
Dimensions (DxWxH): 55×53.50×23.75″
Net Weight: 290lbs
Mobility: Available with optional 3″ locking swivel casters or custom dollies
