MANTARRAY 60
KEY FEATURES
• Superior Pattern Control
• Extremely High 108db Sensitivity
•16 M10 Flypoints with optional L-Track or Flybar Accessories
APPLICATIONS
Optimized for 2 per side operation, for a nominal 120 degree horizontal dispersion. Superior imaging and array ability provides clean, high output sound to ALL of the audience.
The PS212-64 is a high output, arrayable Point Source design featuring a nominal 60×40 (HxV) pattern, and 108db sensitivity from 200hz-20khz. The Enclosure utilizes 2 12 neodymium mid woofers, horn loaded, with a nested 1.41 exit Coaxial Compression Driver mounted on a 60×40 horn. The Coaxial Compression Driver is responsible for everything above 750hz hold pattern extremely well off axis, which is key for side by side arraying of point source designs. The Mantarray is available as an 4 ohm or 16 ohm passive enclosure with optimized crossover network.
System Alignment: Nested Coaxial Point Source W/Symmetrical 12″ horn Loaded Mid
System Response (10db): 100hz-20khz
Frequency Response (-3db): 200-20khz
Power Rating (Continuous Program Peak): 800w/16000w/3000w
Sensitivity (Iw/I meter): 108db
Nominal Impedance: 4 or 16 OHMs
Recommended Processing: 165hz or higher hi-pass
Enclosure Construction: Precision CNC construction,12mm Baltic Birch
Exterior Coating: Polane (Custom Colors Available)
Grille Specifications: N/A
Dimensions (DxWxH): 24x22x30.5″
Net Weight: 100LBS
Available with stack hardware, fly hardware, and road case
