THE BATTLEAXE

KEY FEATURES

Unparalleled LF performance

Useable Output to 25hz

Extreme Powerhandling

APPLICATIONS

Suitable for any application where extreme low frequency extension

and output is required.



The 21FLH28,code name, “The BattleAxe” is a high intensity Front Loaded Horn designed for very deep extension, with an intended passband 28hz-100hz, employing a 24db/octave 25hz buttersworth hipass.



The enclosure is loaded with a 21′ long-throw subwoofer.  This enclosure is optimized for clusters of 4 or more, with optimum sensitivity being achieved from a block of 8. However, the output from a  single BattleAxe is nothing short of stunning.



The enclosure is available in passive only.

System Alignment: 21 Inch loaded Front Loaded Horn

System Response (-10db): 22hz

Frequency Response (-3db): 28hz-150hz

Power Rating (Continuous Program Peak): 1700w/3400w/7000w

Sensitivity (Iw/I meter): 107db

Nominal Impedance: 4ohm or 8ohm Available

Reccomended Processing: 4 Ohm 25hz, 24 db/octave Buttersworth Hi-pass, 60-100hz Low-pass

Enclosure Construction: Precision CNC construction, 18mm Baltic birch 30mm baffle

Exterior Coatings: Polane (Custom Colors Available)

Grille Specifications: Optional 16 Gauge Black Powder-coated Steel

Dimensions (DxHxW): 52.5x50x25.5 inches

Net Weight: 340lbs

Mobility: Available with OPTIONAL 2″ Locking swivel casters or custom dollies
